CMM Inspection Services | China-High-Quality-Parts

Consistently Delivering Machining Excellence

China High Quality Parts uses state-of-the-art, fully automated CMMs (Coordinate Measuring Machines) and powerful PC-DMIS (Personal Computer - Dimensional Measuring Interface Standard) software. To measure and verify critical external and internal part dimensions, complex geometry, overall machine tool output, and other vital features as specified. An outside IEC 17025 accredited calibration facility oversees our rigorous calibration system. All of our facilities are climate controlled at 70°F ±2° with relative humidity below 40% to ensure a stable testing and manufacturing environment.

For the highest quality parts, made to print, the first time, China High Quality Parts is your world-class precision machine shop!

Inspection Capabilities Summary

Part Size:
Bridge CMM Capacity of 79” x 130” x 59” at 14,300 lbs.

Deep Feature Probing - CW43L wrist offers infinite rotation and probing depths to 38.9”
Full Contact Analog Scanning - Utilizing Renishaw SP25M probe system
Exceptional Accuracy - ISO10360 accuracy statement is 5.5+L/286 MPEe
CMM inspection is available at our Shenzhen, and Dongguang locations

Machined Feature Inspection:
External and internal dimensions, external and internal geometry, boring, counterboring, countersinking, drilling, facing, gear hobbing, internal forming, knurling, milling, necking, parting, pocketing, profiling, reaming, shoulder facing, spline, tapping, threading (external, internal), turning (contour, form, taper, straight), thread milling, surface finishing, and other features as specified

Equipment Brands:
Hexagon - Please refer to our Equipment List for CMM information and capabilities.

Coordinate Measuring Machine CMM Overview

A process engineer or quality lab technician generates CMM programming to read and verify critical component markers established by our engineering evaluation process. Machined parts or assemblies rest upon or are affixed to the stationary granite measurement table, or held in place by use of a fixture. The CMM probe travels on the Z, Y, and X-axis precisely interacting with the part as the PC-DMIS programming dictates, recording every marker and bringing alert if an issue is present. Machining parameter adjustments quickly result when observing variation in the machining process. The CMM testing process gathers a wide range of precise measurements and verifies even the most complicated part geometry.

Photo of Coordinate Measuring Machine and Workpiece

CMM Anatomy

Probe - The instrument that travels on the Z, X, and Y-axis that comes in physical contact with the part
Vertical Ram - Holds the probe and moves on the Z-axis (up and down)
Component - The machined part or assembly the CMM machine is measuring
Granite Measurement Table - An extremely heavy-duty, stationary bed that holds parts and fixtures for inspection
Bridge - Allows the probe and ram to travel on the Y-axis (left and right)
Carriage - Travels the length of the granite measurement table on the X-axis (front and back), transporting the bridge, vertical slide, ram, and probe
Pendant/Jogbox - The interface a quality technician uses to manually program and control how a CMM operates
